Features
- Compact and lightweight
- Automatically performs beveled or straight cuts into pipes
- Torch maintains tip-to-work-piece distance based on trigonometry function of H-Lever
- Rotating gas manifold keeps hoses from becoming tangled
- Automatic Tip Stand Off ensures higher accuracy during bevel cutting
- Can be used to cut circles on flat plate with an optional bevel edge
- On/Off drive positions cutting tip accurately and quickly
| PRODUCT NO. | MODEL | DIMENSION (mm) | CUTTING THICKNESS (mm) | TOUCH ROTATION SPEED (rpm) | DIAMETER OF CIRCLE CUTTING (mm) | MAX. HEIGHT OF CUTTING CURVE (mm) | WEIGHT (kg) |
|---|---|---|---|---|---|---|---|
| 351660004 | AW600-04 | 1060 X 560 X 820 | 6-50 | 0.14-1.2 | 80-600 | 96 | 50 |
