Features
- Special design for thick wire SAW, adopt Ø 3-5 mm wire and matches with power source RTA-1000/1250.
- Modular construction enables all parts to be dismounted easily.
- Has four wheel driving and six degree of freedom adjustment to realize any position welding.
- Applicable for carbon steel, stainless steel, copper and copper alloy welding.
- Wire feeding assembly adopts planetary gear reducer system with large moment and high stability of wire feeding.
- Contact tips adopt eccentric design for strong conductivity.
Specifications
| Wire Diameter (mm) |
Ø 3.0 – 6.0 |
| Arc Strike Model |
Scraping, fixed |
| Welding Speed Range (cm/min) |
25-170 |
| Wire Feeding Speed (cm/min) |
20-200 |
| Head Moving Range (mm) |
100 x 100 |
| Head Rotating Angle |
360˚ |
| Head Weaving Angle |
45˚ |
| Head Tilting Angle |
90˚ |
| Flux Hopper Capacity |
10 |
| Wire Reel Capacity (kg) |
25 |
| Dimensions (L x W x H) (mm) |
950 x 500 x 870 |
| Weight (kg) |
48 |
| Weight |
48 kg |
| Dimensions |
95 × 50 × 87 cm |
