Vertical Diaphragm Assembly Machine Model No. AWVD12


  • To assemble and weld the middle clapboards in the BOX type beam.
  • Adopt cylinder compacting when assembling to determine the position before welding the workpiece by spot.
  • The rotation work table is then turn over for 180˚ by motor after the welding is done on 1 face.
  • The work table is turn to the level after welding on another face, then the cylinder is loosen and unload.
